LED Turn Signal Kit
This is a 12 volt LED Turn Signal Kit with 2 Amber (front) and 2 Red (rear) or your choice of all Amber D.O.T. approved LED lights. Our LED turn signal kit comes with two 4″x 2″ inch rectangular amber (front) LED lights. In addition, two 4″x 2″ inch rectangular red (rear) LED lights. However, you can substitute the rear lights for the ¾” SM LED lights to give your UTV a custom look.
Why Our Turn Signal Kits are Completely Independent
I get asked a few times every month, why don’t you use the UTV or ATV rear OEM lights for the rear turn signals? The answer is very simple. I developed my Turn Signal Kits (TSK) to be completely independent for THREE main reasons. ONE, you do not want any possible feedback from the LED Electronic Flasher into the ECU of your UTV or ATV. Consequently, electronic feedback can cause problems with your ECU and they are very expensive to replace. TWO, you do not want to affect (invalidate) your manufactures warranty by tapping into any existing OEM lights or wiring. THREE, you want both rear stop lights when activating the turn signals (like our automobiles), not just one. As a result, with all my different turn signal kits you will never have these concerns or issues.
LED Turn Signal Kit Specifications
This LED turn signal kit comes with a turn signal switch. First of all, it has a pilot light for the turn signals and 4-way emergency flashers (hazard warning). Secondly, the turn signal switch has a pull out flare tab for the 4-way hazard lights. Furthermore, it comes with the hardware to mount it to your steering column.
The four LED Lights are 4”x 2” rectangular with 16 (LED) Light Emitting Diodes each. Secondly, they have a polycarbonate lens & housing. Finally, they are hard wired with encapsulated electronics to eliminate corrosion. Likewise, you can substitute the 4″x 2″ (rear) LED lights for the ¾” SM LED lights to add a custom look.
This special LED Flasher has the 3 pin connections for LOAD, PILOT and POWER. Also, the electronic LED flasher is quite, no annoying clicking sounds.
Our LED turn signal kit includes: 2 Amber and 2 Red or all Amber D.O.T. approved LED lights. Secondly, the turn Signal Switch with hardware to mount it to your steering column (see TSS mounting hardware). Also, the LED Flasher, ATC in-line fuse holder, 3 amp fuse, self tapping screws for mounting the lights and flasher. In addition, the mounting installation instructions with wiring instructions & diagram. Most importantly, with our LED Turn Signal Kit you get all the help and support you need from EZ Turn Signal Kits.
LED Turn Signal Kit Important Note
Note FYI: I have heard people say that a column mounted Turn Signal Switch (TSS) is in the way of you entering and exiting the unit, not true! Secondly, they say you will bump the TSS lever with your legs and even break that lever, again not true! In other words, I am 6’3″ and 250 pounds, I have never bumped the TSS and I use my units multiple times a day. Finally, I have sold thousands of the column mounted TSS and never had a customer complain about bumping or breaking one.
LED Turn Signal Kit Installation
This kit can be easily installed, it does not go into any factory wiring and above all it will not void your manufactures warranty! In addition, each wire has a different color and the wiring diagram shows where each colored wire goes. Above all, I include my phone number and e-mail address with the instructions. Therefore, if you have any questions about your installation you can contact me.
This turn signal switch has been installed on thousands of units, very nice and easy to operate. The Motor Vehicle Department and your local police departments will be impressed. Most noteworthy, everyone who rides on the street or off road (dunes/congested areas), should have turn signals for their added safety.
The LED Turn Signal Kit will fit most of the UTV side-by-side full-size models (check the TSS mounting hardware).
In addition you may like amber lights front and rear, order from the drop down box Light Options: Amber Kit: All 4 Amber lights.
Likewise you can substitute the 4″x 2″ (rear) LED lights for the ¾” SM LED lights to add a custom look. Order from the drop down box Light Options: 2 Amber ¾” LED Lights or 2 Red ¾” LED Lights or 4 Amber ¾” LED Lights or 4 Red ¾” LED Lights.
LED Turn Signal Kit Options
We have some Custom Kit Brackets, UTV Wire & Connector Kit and LED Dash Indicators. Therefore, you may want to use these with your LED Turn Signal Kit. That is to say, any of these options purchased with your LED turn signal kit, will save you time & money!
Option1 – Your choice of lights to make your UTV have a custom look.
Option2 – Turn Signal Switch (TSS) mounting hardware for your particular year, make and model.
Option3 – The 09-20 Ranger 570-800-900-1000 XP/HD/HO/Crew/6×6/Diesel Full-size Front Flare Brackets (FFB). Above all these will give your Ranger full-size models an OEM look. See notes 1 thru 3.
Note1: These FFB’s DO NOT work on the Ranger Mid-size EV/ETX/400/500/570/800 models.
Note2: The 2018-20 Ranger 1000 XP does not have front flare openings in their new front design.
Note3: Also, the 2019-20 Ranger Crew XP 1000 does not have front flare openings in their new front design.
Option4 – If you don’t have a rear bumper, you might want to use our Rear T-Brackets (4″ x 2″ lights only).
Option5 – UTV Wire and Connector Kit, to clarify this kit will make it easy to connect your turn signals.
Option6 – Dash Indicators for those that want one or two dash indicators.
You can order whatever options you want with your LED Turn Signal Kit by using the drop down (∇) menus.
Copyright © 2008-2021
Looking for a SM LED Turn Signal Kit checkout our SM LED TSK #104.
Have you seen the new Polaris models?
Bruce Nofftz – verified (verified owner) –
Hi Cisco, In 2008 I bought a turn signal and horn kit from you for a new Kawasaki Mule. The ones I have are probably 2 inch high and 4 inches wide with several little LED bulbs inside. So far so good, never any problems. Are your turn signals still the same size as in 2008?
I am looking at perhaps getting another side by side. My question is do you make a turn signal kit and a horn kit for a John Deere gator XUV835? Also, do you make kits for a Can-am Defender Limited?
I hope to hear back from you soon. Thanks, Bruce
Cisco’s reply:
Hello Bruce,
Good news: Yes, I still have the original TSK# 105 with the 4″ x 2″ LED
lights. I have developed a few more Turn Signal Kits (TSK) using the new
brighter 3/4″ LED lights too. I build TSK & Horn Kits for all the different UTVs and ATVs.
Bad news: I retired hoping that someone would buy my company and keep it
going as it is a great money maker. I sold all of my inventory of TSK,
Horn Kits and License Plate Brackets. I will not be producing any more as
I have retired. My company is for sell and when someone takes it over
they will be manufacturing all of the kits immediately.
Thank you for all your time and support.
Let me know if I can be of further assistance.
Again, thank you and have a great day,
Cisco
Dave Wright – verified (verified owner) –
Easy to order online, great kits with good instructions. A pleasure to do business with, I will highly recommend this company, thank you.
Ben Johnson – verified (verified owner) –
Great communication. A pleasure to do business with.
Jared Dick – verified (verified owner) –
Great kit, plenty of hardware, wire and connectors.
Rick Garrett – verified (verified owner) –
Quality product! Easy to follow instructions! Knowledgeable, friendly seller!
David Tonderum – verified (verified owner) –
I wanted to tell you how happy I am with my turn signal and horn kit from you. Everything worked perfect. I was able to do all my wire connections, relays and power connections right under the hood of my 2019 Textron Havoc X. There is a ground, 12 volt and switched power bar right there. I bent your T-brackets for the front signals at about 90 degree and they mounted very nice under the front nose of the machine. I never had to remove any body panels to install the whole kit. Only drilled one hole for the horn button. I have some buddys that will be ordering from you soon.
Thank you for the quality products, Dave
Rick Wojcik – verified (verified owner) –
Cisco, thank you, I still have my 2007 Polaris Ranger and the turn signal kit I got from you 10 years ago still functions perfectly, great kit!
Bill Peirce – verified –
I just got your 105 kit installed on my Polaris 570-6 and it works great. Thank you for producing a quality kit and for the great instructions.
Cliff Polanski – verified –
Nice kit, great product and super fast shipping, thank you!
Michael Krall – verified –
Great product from a great company! I highly recommend this website!
Levi Tarwater – verified –
We received the LED Turn Signal Kit (stock# 105), got it installed on my 2015 Gravely Atlas JSV 3000 and all went well, thank you!
David Gilkerson – verified –
Here are some pictures of your LED Turn Signal Kit (stock# 105) on my 2014 Gravely Atlas JSV 3000. The install was simple and easy, they look and work great, thank you!
Terry McGee – verified –
Cisco, the bike is a 2002 Dyno Roadster. It’s a stretched beach cruiser and is 7’10” long with the springer forks. I call her “Big Red”. She should do about 40mph, get around 100 mpg running a 2hp/2 stroke engine and the turn signals (stock# 105) are REALLY cool! Thank you for all your help.
Gene Kroell – verified –
I received and installed my turn signal kit (#105) on my 2008 Arctic Cat Prowler 700. I had no trouble with the installation. This Arctic Cat Prowler has the tilt steering. I installed the rear signal lights on the ROPS cage. I mounted them high due to the fact the stop and tail light is at the top of the ROPS. I built two brackets for the front lights and mounted them at the bottom of the windshield to make them visible. I used a stainless steel hose clamp for the TSS mounting strap, as per your recommendation. I also bored a ½ inch hole in the dash and fed the main wiring harness thru the dashboard. Hey, they work great!
Henry Leydekkers – verified –
Cisco, as promised here are a few pictures of our 2003 Kawasaki Mule with the front and rear turn signal lights, the turn signal switch, the LED flasher, the horn and the LED license plate bracket. The TSK #105, horn kit and LED license plate bracket were all simple to install. Your instructions were very easy to read and follow, especially with the different color wirings. The EZTSK wire & connector kit general instructions were simple and everything is just working great.
Johnny Wood – verified –
I just wanted to say that these LED turn signals (#105) are great! I have received several comments about them and asked where I purchased them. I live in an area where UTV’s are common and these signals make it safer when I travel and are very bright. The installation was very easy and simple with your instructions. Here are a couple of pictures of the installed lights. The front of my 2007 Arctic Cat Prowler 650 XT has LED parking lights (centered) that I installed prior to purchasing and installing your turn signal kit. Thank you again for everything.
Robert Worrell – verified –
I installed your TSK #105 on my 1929 Ford Model A. it was easy to install as I followed your instructions, no problems and it works great! It really looks nice on the car, thank you for developing high quality kits. Also, thank you for all your help, Robert W.
Cisco Folk – verified –
I installed this LED Turn Signal Kit (#105) on my Polaris Ranger 900 XP. It was easy to install, the instructions were simple to follow and their was more than needed to complete the job. I got the optional 4 Red SM 3/4″ Lights, the custom TSS hardware, the Front Flare Brackets (FFB’s), the UTV wire connector kit and the two dash indicators. Everything went together very nicely and they all work great! This is a great quality made kit and you get all the support you need from EZ Turn Signal Kits!
